High weatherability electrophoretic paint for engineering machinery
Product Introduction :
HR-4000LB/HR-4010 Epoxy acrylic Gray Cationic Electrocoat is HLS Paint (Shanghai) Co., Ltd., the eighth generation of independent research and development of electrophoretic coating.
This coating by epoxy acrylate modified, the film also has excellent corrosion resistance and weatherability, smooth appearance and full, suitable as a base topcoat system. In addition, the lead, cadmium, chromium, mercury and other heavy metals, two-component, water dispersible resin, at the same time, previous generations of the product characteristics, have good adaptability to the galvanized steel, almost can be applied to all metal coating
such as: cold hot rolled steel, galvanized steel, aluminum, zinc Aluminum Alloy plate, stainless steel plate
This product features shown below :
| Good stability of bath can adaptable for a longer updating cycle | High penetration and good uniformity of internal and external. | Good weather resistance, very suitable for car body, car chassis, electric, three wheeled motorcycle frame and other industries. |
The main component Matrix resin :
1,Matrix resin: Acrylic modified epoxy resin
2,Neutralizing agent: organic acid
3,Additives: surface active agent, prevent shrinkage cavity agent
Bath on site management project :
Good bath data and coating quality, from the strict parameters management and maintenance of equipment, production line according to its own reality time situation, can have different management project and specifications, recommend the construction parameters see the table below for reference:
| Classification | Project | Control Data | Testing frequency |
| New bath | Anolyte |
| Electrophoresis tank | Ratio | 1:(6-8) | -- | |
| Ripening time | 24-48 | -- | |
| Solid ( 120 ℃ /1h ,% ) | 15±5 | -- | once a day |
| PH | 5.5-6.0 | 2.0-3.5 | once a day |
| Conductivity ( μs/cm ) | 1000±500 | 1400±900 | once a day |
| P/B | 0.20-0.30 | once a week |
| L panel | Smooth horizontal plane and vertical plane without obvious differences | once a week |
| Solvent content (%) | 0.5-1.8 | once a week |
| Liquid level Fall head (cm ) | 10-15 | once a day |
| ED voltage( V ) | 0-300 | once a day |
| Break voltage ( V ) | ≥350 | once a week |
| Bath temperature ( ℃ ) | 28-35 | once a day |
| ED time( S ) | 60-180 | once a day |
| UF － 1 Tank | Solid content (%) | ≤2.0 | once a day |
| UF － 2 Tank | Solid content (%) | ≤0.8 | once a day |
| Baking furnace | Provisions furnace temperature( ℃ ) | 170-180 | once a day |
| Curing conditions | Drying temperature |
(165-175)℃×(20-30)min (With content holding time) | once a day |
Construction equipment :
Cathodic electrophoretic coating construction in the electrophoresis tank, so need to have the following equipment:
| Electrophoresis tank | Circulation devices (including filter, fill the paint device) | DI water equipment |
| DC power supply and the power supply unit | Anode box (tube) and circulation device | Ultrafiltration device |
| Cleaning devices | Heat exchanging equipment | Curing device |
Customer production site :
